Unstable Frequency in 3-Phase Sine Wave Generation on STM32F030R8T6

ARM Cortex-M0 Clock Configuration and Timer Precision Issues

The core issue revolves around the instability of the generated 3-phase sine wave frequency, which fluctuates between 50 Hz and 200 Hz when using the STM32F030R8T6 microcontroller. The primary suspect lies in the clock configuration and timer settings, which are critical for precise waveform generation. The STM32F030R8T6 relies on the High-Speed Internal (HSI) oscillator as the clock source, which is known for its lower accuracy compared to the High-Speed External (HSE) oscillator. The HSI oscillator has a typical accuracy of ±1%, but this can vary significantly with temperature and voltage fluctuations, leading to frequency instability in time-sensitive applications like sine wave generation.

The timer peripheral (TIM1) is configured in center-aligned PWM mode with an auto-reload register (ARR) value of 1199, targeting a 40 kHz PWM frequency. However, the sine wave frequency instability suggests that the timer is not consistently maintaining the desired period. This could be due to improper clock tree configuration, insufficient timer resolution, or incorrect interrupt handling. The timer’s update interrupt is used to adjust the duty cycles of the PWM signals to generate the sine wave, but any inconsistency in the interrupt timing will directly affect the output frequency.

Additionally, the sine wave generation relies on a precomputed sine table with 100 entries, and the phase shift between the three waveforms is achieved by offsetting the table indices. While this approach is mathematically sound, any timing irregularities in updating the duty cycles will disrupt the phase relationship and frequency stability. The issue is further compounded by the use of the HSI oscillator, which exacerbates timing inaccuracies.

HSI Oscillator Inaccuracy and Timer Interrupt Latency

The instability in the generated sine wave frequency can be attributed to two main factors: the inherent inaccuracy of the HSI oscillator and potential interrupt latency in the timer update ISR. The HSI oscillator, while convenient for its internal availability, is not suitable for applications requiring high timing precision. Its frequency can drift due to environmental factors, leading to inconsistent timer periods. This drift directly impacts the PWM frequency and, consequently, the sine wave frequency.

The timer interrupt service routine (ISR) is responsible for updating the PWM duty cycles based on the sine table. Any delay in executing the ISR, whether due to interrupt prioritization, nested interrupts, or inefficient code, will introduce jitter in the duty cycle updates. This jitter manifests as frequency instability in the output waveform. The current implementation does not account for potential delays in the ISR, nor does it include mechanisms to measure or compensate for such delays.

Furthermore, the timer’s auto-reload register (ARR) and prescaler (PSC) settings are critical for achieving the desired PWM frequency. The ARR value of 1199, combined with a PSC of 0, targets a 40 kHz PWM frequency when the system clock is 48 MHz. However, any deviation in the system clock frequency due to HSI inaccuracy will result in an incorrect PWM frequency. This, in turn, affects the sine wave frequency, as the sine table updates are synchronized with the PWM period.

Optimizing Clock Configuration and Timer Settings for Stable Frequency

To address the frequency instability, the following steps should be taken to optimize the clock configuration and timer settings:

1. Switch to HSE Oscillator: Replace the HSI oscillator with an HSE oscillator for improved clock accuracy. The HSE oscillator, typically a crystal or ceramic resonator, offers significantly better frequency stability, often with an accuracy of ±10 ppm or better. This will ensure a stable system clock, which is essential for precise timer operation.

2. Verify Clock Tree Configuration: Ensure that the clock tree is correctly configured to use the HSE oscillator as the system clock source. This involves setting the appropriate bits in the RCC_CFGR register and waiting for the clock switch to complete. The following code snippet demonstrates the necessary configuration:

   RCC->CR |= (1 << 16); // Enable HSE
   while (!(RCC->CR & (1 << 17))); // Wait for HSE to stabilize
   RCC->CFGR |= (1 << 0); // Select HSE as system clock
   while ((RCC->CFGR & (3 << 2)) != (1 << 2)); // Wait for clock switch


3. Calibrate Timer Settings: Recalculate the timer’s auto-reload register (ARR) and prescaler (PSC) values based on the new system clock frequency. For example, if the HSE oscillator is 8 MHz and the PLL is configured to multiply the clock to 48 MHz, the ARR value of 1199 will still yield a 40 kHz PWM frequency. However, it is essential to verify these calculations and ensure that the timer is operating at the intended frequency.

4. Minimize Interrupt Latency: Optimize the timer update ISR to minimize execution time and reduce interrupt latency. This can be achieved by simplifying the ISR code, avoiding unnecessary computations, and ensuring that the ISR has the highest priority. Additionally, consider using DMA to transfer the sine table values to the timer’s capture/compare registers, offloading this task from the ISR and further reducing latency.

5. Implement Frequency Monitoring: Add a mechanism to monitor the generated sine wave frequency in real-time. This can be done using an additional timer configured in input capture mode to measure the period of the sine wave. Any deviations from the target frequency can be logged or used to dynamically adjust the timer settings, providing a feedback loop for frequency stabilization.

6. Temperature and Voltage Compensation: If environmental factors are suspected to contribute to frequency instability, consider implementing temperature and voltage compensation mechanisms. This can involve measuring the ambient temperature and supply voltage using the microcontroller’s internal sensors and adjusting the timer settings accordingly to maintain a stable output frequency.

By addressing these factors, the frequency instability in the 3-phase sine wave generation can be significantly reduced, resulting in a stable and accurate output waveform. The use of an HSE oscillator, combined with optimized timer settings and interrupt handling, will provide the necessary precision for this application.
